paulrickards »
@paulrickards@mastodon.social

I was surprised to learn that the Yamaha PortaSound MP-1 does exist so I bought one. It’s a strange confabulation of a keyboard and pen plotter! It came with a handy hard shell case which certainly helped during shipping.

A Yamaha PortaSound MP-1 music keyboard in silver inside a black case. The keyboard has lots of buttons and sliders at the top, a speaker to the left and, a tiny pen plotter to the right.

Alt...A Yamaha PortaSound MP-1 music keyboard in silver inside a black case. The keyboard has lots of buttons and sliders at the top, a speaker to the left and, a tiny pen plotter to the right.

Oblique photo of a Yamaha PortaSound MP-1 music keyboard in silver inside a black case. The keyboard has lots of buttons and sliders at the top, a speaker to the left and, a tiny pen plotter to the right.

Alt...Oblique photo of a Yamaha PortaSound MP-1 music keyboard in silver inside a black case. The keyboard has lots of buttons and sliders at the top, a speaker to the left and, a tiny pen plotter to the right.

    paulrickards »
    @paulrickards@mastodon.social

    The pen plotter itself is the same tiny Alps that’s used in other small plotters like the Tandy TRS-80 PC-2 but with only a single color head instead of the four color rotating head. This is the first I’ve seen this variation before. The pen eject is the tiny lever on the head.

    The gears were predictably broken but I used my 3D printed replacements and it works now.

    A tiny pen plotter loaded with a pen and paper with the lid off. To the left are a few music keyboard keys and a tube of pens.

    Alt...A tiny pen plotter loaded with a pen and paper with the lid off. To the left are a few music keyboard keys and a tube of pens.

    The right side of a keyboard that has a plotter built in with paper loaded partially coming out.

    Alt...The right side of a keyboard that has a plotter built in with paper loaded partially coming out.

      paulrickards »
      @paulrickards@mastodon.social

      The idea was that you’d play a melody and it would plot what you just played. Sounds great, right?

      In practice, it plots so slow you’re waiting two minutes to plot just a few measures.

      ..But it does work!

      It says disco on the plot because that’s the rhythm that was selected. Bonus points if you know the melody. 🎼 🎶

      Right side of a music keyboard with a pen plotter with a plotted score sitting on top and a few in the background.

      Alt...Right side of a music keyboard with a pen plotter with a plotted score sitting on top and a few in the background.

        paulrickards »
        @paulrickards@mastodon.social

        You can also plot from stored memory. Here’s a quick video of the Yamaha PortaSound MP-1 where I take the lid off the pen plotter so you can see it plotting better. It fills in the eighth notes with a quick zig zag fill.

        Alt...A video of a tiny pen plotter inside a music keyboard plotting a music staff and several notes with a tiny ball point pen by moving the paper up and down and the pen left and right.

          paulrickards boosted

          paulrickards »
          @paulrickards@mastodon.social

          If you like pen plotters in weird things like I do, you’ll like my blog post about typewriter plotters (and other devices)!

          biosrhythm.com/?p=2143

            paulrickards »
            @paulrickards@mastodon.social

            CMY wavy rainbow constructed from just three pens and hatch shading.

            CMY ink on 11”x15” watercolor paper using a vintage HP 7585B pen plotter generated and controlled with Python.

            Available in my shop: shop.paulrickards.com/wildcard

            An abstract pen plot on white paper of a rainbow modulated by a sine wave horizontally that consists of colors of the rainbow including magenta, red, yellow, green, blue, and violet. The plot is constructed from just three pen colors of hatch shading that overlap to create new colors.

            Alt...An abstract pen plot on white paper of a rainbow modulated by a sine wave horizontally that consists of colors of the rainbow including magenta, red, yellow, green, blue, and violet. The plot is constructed from just three pen colors of hatch shading that overlap to create new colors.

            Detail from an abstract pen plot on white paper of a rainbow modulated by a sine wave horizontally that consists of colors of the rainbow including magenta, red, yellow, green, blue, and violet. The detail shows a closeup of the individual pen strokes.

            Alt...Detail from an abstract pen plot on white paper of a rainbow modulated by a sine wave horizontally that consists of colors of the rainbow including magenta, red, yellow, green, blue, and violet. The detail shows a closeup of the individual pen strokes.

            Detail from an abstract pen plot on white paper of a rainbow modulated by a sine wave horizontally that consists of colors of the rainbow including magenta, red, yellow, green, blue, and violet. The detail shows a closeup of the individual pen strokes.

            Alt...Detail from an abstract pen plot on white paper of a rainbow modulated by a sine wave horizontally that consists of colors of the rainbow including magenta, red, yellow, green, blue, and violet. The detail shows a closeup of the individual pen strokes.
